The NIBE S1156 is an intelligent, inverter-controlled ground source heat pump with a new, more climate-friendly refrigerant and without an integrated water heater. The heat pump provides optimised savings as it automatically adapts to your home’s heating requirements. The NIBE S1156 is our most energy-efficient ground source heat pump, thanks to innovative technology and our many years of experience.
The NIBE S1156 has a seasonal performance factor of up to 6.22* in SCOP, making it a highly efficient climate system with low operating costs. After connecting a separate water heater of any size, it provides hot water with high performance. The heat pump is designed for houses up to approx. 400 m2 and is available in three output sizes: 1.5–8 kW, 3–13 kW and 4–18 kW. The NIBE S1156 is designed for low noise levels and is suitable for both new builds and when replacing an existing heat source.
With integrated wifi and the possibility of connecting to wireless accessories, the NIBE S-Series will become a natural part of your connected home. The smart technology adjusts the indoor climate automatically, while you exercise complete control from your smartphone or tablet. A high level of comfort and low energy consumption – and you're doing nature a favour at the same time.
HIGH CUSTOMIZATION
Our most energy-efficient ground source heat pump with a seasonal performance factor of up to 6.22.
TOP PERFORMING
A new, more climate friendly refrigerant, high hot water capacity and low noise level.
HIGH COMFORT
User-friendly touchscreen, wireless accessories, and integrated wireless connectivity with energy-saving smart technology for high comfort.
Back-up electric immersion heater - 42kW
The NIBE PCM ground source accessory makes it possible to obtain passive cooling from rock, groundwater or surface soil collectors. Combine with your S Series heat pump for a flexible system. Even while your system is continually heating hot water it will cool your home. NIBE PCM is controlled via the heat pump’s touch control, where both settings and monitoring are handled with an easy swipe. The NIBE S Series is a natural part of your connected home. Smart technology adjusts the indoor climate automatically while you’re in complete control from your phone or tablet. Giving maximum comfort and minimum energy consumption, while doing nature a favour at the same time.
The wireless room thermostat allows you to read and control the temperature of a room or a climate zone from the display of the room thermostat or via the myUplink app in your smartphone. For instance by increasing the hot water production when you have many guests or lower the ventilation for better savings when you are not home. Because it is powered by a rechargeable battery, it is easy to install.
Mount the thermostat in your room and connect it to your NIBE S-Series heat pump.
Back-up electric immersion heater - 26kW
Top cover for ERS MVHR units to conceal ducting. 245mm tall.
Enhances the signal, improving communication between your smart home products when they are placed at a distance from each other. For NIBE S- Series heating installations, the repeater functions as a switch, giving you the opportunity to control it remotely, schedule On and Off times and measure energy consumption.
Plug in the repeater and connect it to your NIBE S-Series heating installation.
Filling connection for filling up the brine. Including insulation. For heat pumps max. 13 kW.
Top cover for ERS MVHR units to conceal ducting. 245mm tall.
NIBE PV is an integrated solution which is based on a fully modular system with several basic sizes: 4 / 8 / 12 / 16 / 20 kW. Each basic package has nominal power of 4 kW and consists of 10 panels, mounting parts and an inverter with communication module, all of which are ready for installation. The solar package can easily be expanded with additional solar panels for optimum use of roof space.
NIBE PV comprises of monocrystalline silicon cell panels which use PERC technology, with an output of 400 Wp. The solar panels are elegant, all-black panels. NIBE PV harnesses sunlight all year round and converts it into electricity. NIBE PV can be connected to your NIBE heat pump* for maximum energy efficiency.
Thanks to smart technology, the product gives you control over your energy consumption and will be a key part of your connected home. The efficient control system automatically adjusts the indoor climate for maximum comfort, and you do nature a favour at the same time. * applies to systems which can be connected to NIBE Uplink and myUplink.
Top cover for ERS MVHR units to conceal ducting. 245mm tall.
The NIBE FLM S45 is an exhaust air module with built-in fan, specially designed for combining recycling of mechanical exhaust air with a NIBE ground source heat pump, providing an integrated solution for ventilation, hot water and heating.
The NIBE FLM S45 has a high fan capacity and low noise level. Energy is recovered from the ventilation air; even when the heat pump is not in operation, energy is stored in the ground or soil collector and exhaust air energy is thus put to maximum use.
The NIBE S Series is a natural part of your connected home. Smart technology adjusts the indoor climate automatically while you’re in complete control from your phone or tablet. Giving maximum comfort and minimum energy consumption, while doing naturea favour at the same time.
Three phase back-up electric immersion heater - 15kW
The NIBE PCM ground source accessory makes it possible to obtain passive cooling from rock, groundwater or surface soil collectors. Combine with your S Series heat pump for a flexible system. Even while your system is continually heating hot water it will cool your home. NIBE PCM is controlled via the heat pump’s touch control, where both settings and monitoring are handled with an easy swipe. The NIBE S Series is a natural part of your connected home. Smart technology adjusts the indoor climate automatically while you’re in complete control from your phone or tablet. Giving maximum comfort and minimum energy consumption, while doing nature a favour at the same time.
Combine with your NIBE S Series heat pump for passive or active cooling. It will keep you cool even while your system is continually heating hot water.
The NIBE ERS 30-400 is a heat recovery ventilation unit with high temperature efficiency up to 94% and low energy consumption. The heat recovery ventilation unit is used in houses with areas up to approx. 350 m2. The NIBE ERS 30-400 is designed for installation with a NIBE ground source heat pump or a NIBE air/water heat pump for a complete heating and ventilation system. The heat recovery ventilation unit is easily controlled by the heat pump. Thanks to smart technology, the product gives you control over your energy consumption and will be a key part of your connected lifestyle. The efficient control system automatically adjusts the indoor climate for maximum comfort, and you do nature a favour at the same time.
This wireless sensor allows you to read the temperature and humidity in a room or climate zone using the myUplink app. On the heat pump you can see the current room temperature or change it in °C. THS 10 replaces the fixed indoor sensor. Because it is battery powered, it is easy to install.
Mount the sensor in your room and connect it to your NIBE S-Series heating installation.
Wall console BAU 40 for wall mounting.
The NIBE VPB 500/750/1000 is an efficient, copperlined hot water tank with a wide range of applications which is developed for connection to a heat pump, gas or oil boiler. The NIBE VPB 500/750/1000 has insulation made of Neopor and polyester fleece, which provides low energy loss. The insulation and outer shell are detachable to facilitate installation. The NIBE VPB 500/750/1000 is designed for buildings with large hot water requirements and can be connected in parallel for maximum capacity.
This wireless sensor allows you to read the CO2, temperature and humidity level in a room or climate zone using the myUplink app. For NIBE S-series heating installations with ventilation the indoor comfort level can automatically be adjusted to give you a comfortable indoor climate. For example, you can increase ventilation and lower the CO2 level when there are a lot of people present or lower the ventilation to further reduce your energy costs. Because it is battery powered, it is easy to install, but it can also operate with an external power source using a micro USB.
Mount the sensor in your room and connect it to your NIBE S-Series heat and ventilation installation.
4-Pipe Passive/Active Cooling Accessory
Wireless smart radiator thermostat
Passive cooling. PCS 44 is used when heat pump is installed in an installation with passive cooling.
The NIBE RMU S40 is a room unit with 2,8” touch display with built in temperature and humidity sensors. It is used to control and monitor your NIBE S series heat pump/indoor module from another room in the house than the room where the heat pump is placed.
The NIBE S Series is a natural part of your connected home. Smart technology adjusts the indoor climate automatically while you’re in complete control from your phone or tablet. Giving maximum comfort and minimum energy consumption, while doing nature a favour at the same time.
An accessory that allows pool heating using heat pump. Max 18 kW. The heat pump controls the reversing valve, pool circulation pump and any heating circuit circulation pumps via POOL 40.
HTS 40 is an accessory that records humidity and temperature.
Extension frame.
NIBE SOLAR 40 enables solar heating with your heat pump. With additional solar panels and VPAS you get a complete system.
NIBE SOLAR 42 enables solar heating with your heat pump. With additional solar panels and VPBS you get a complete system.
Auxiliary relay HR 10 is a connection box housing a contactor and a rotary selector switch. It is used to control external 1 to 3-phase loads such as oil burners, immersion heaters and pumps.
Communication module that translates Modbus RTU, from a solar inverter, to Modbus TCP/IP, for the heat pump to control the solar inverter
Accessory card. AXC 40 is used to enable connection and control of Mixing valve controlled additional heat, Pump for hot water circulation, Groundwater pump
ECS 40 is used when heat pump is installed in houses with up to four different climate systems that require different flow line temperatures, for example, in cases where the house has both a radiator system and an under floor heating system.
Allows the heat pump to control a second heating circuit (zone) with a different temperature requirement. For more than 80 m² of underfloor heating
Height (mm)
1500
Width (mm)
600
Depth (mm)
620
Net weight (kg)
165
Product efficiency class room heating, 35 °C
A+++
Product efficiency class room heating, 55 °C
A+++
System efficiency class room heating, 55 °C
A+++
System efficiency class room heating, 35 °C
A+++
Efficiency class water heating
A+
Refrigerant amount, CO2 equivalent (ton)
0,54
Declared tap profile
XL
