NIBE VVM S500

NIBE EMK 500

The NIBE EMK 500 energy metering accessories provides installers with a reliable way to monitor the actual energy delivered by a NIBE heating system, measuring both flow and temperature difference within the charge circuit to determine output for heating, domestic hot water or additional climate zones. The kit includes a precision flow meter, pre-terminated communication cable and the necessary pipework and unions for straightforward installation. The EMK 500 is suitable for higher-flow systems.

NIBE DEH S500

DEH S500 is used to enable connection and control of external additional heat.

NIBE ELK 42

Back-up electric immersion heater - 42kW

NIBE ELK 26

Back-up electric immersion heater - 26kW

NIBE ELK 213

The NIBE ELK 213 acts as source of supplementary heat for NIBE heat pump systems, for up to 13kW output. It integrates seamlessly with NIBE systems, allowing the heat pump to activate electric backup automatically during peak loads, cold weather or rapid reheat periods. Multi-stage output control ensures smooth modulation and avoids unnecessary electrical demand. It also incorporates built-in safety features, including thermostats, temperature limiters and circuit protection, making the range suitable for compliant, predictable and installer-friendly system design.

NIBE HTS 40

HTS 40 is an accessory that records humidity and temperature.

NIBE EME 20

Communication module that translates Modbus RTU, from a solar inverter, to Modbus TCP/IP, for the heat pump to control the solar inverter

NIBE ECS 41

The NIBE ECS 41 kit allows installers to add one or more additional heating circuits to a NIBE heat pump installation where different supply temperatures are required, such as radiator and underfloor heating combinations. Each kit includes a dedicated AXC accessory module, shunt valve, shunt motor, circulation pump and temperature sensor, enabling the new zone to run as a fully controlled climate system with independent flow temperature, heating curve and pump operation. The ECS 41 is sized for larger UFH areas above 80 m².

NIBE ECS 40

ECS 40 is used when heat pump is installed in houses with up to four different climate systems that require different flow line temperatures, for example, in cases where the house has both a radiator system and an under floor heating system.

NIBE ACS 310

Active cooling

NIBE AXC 40

Accessory card. AXC 40 is used to enable connection and control of Mixing valve controlled additional heat, Pump for hot water circulation, Groundwater pump

NIBE ELK 15

Three phase back-up electric immersion heater - 15kW

NIBE HR 20

NIBE POOL 500

NIBE HR 10

Auxiliary relay HR 10 is a connection box housing a contactor and a rotary selector switch. It is used to control external 1 to 3-phase loads such as oil burners, immersion heaters and pumps.

NIBE PV

NIBE PV is an integrated solution which is based on a fully modular system with several basic sizes: 4 / 8 / 12 / 16 / 20 kW. Each basic package has nominal power of 4 kW and consists of 10 panels, mounting parts and an inverter with communication module, all of which are ready for installation. The solar package can easily be expanded with additional solar panels for optimum use of roof space.

NIBE PV comprises of monocrystalline silicon cell panels which use PERC technology, with an output of 400 Wp. The solar panels are elegant, all-black panels. NIBE PV harnesses sunlight all year round and converts it into electricity. NIBE PV can be connected to your NIBE heat pump* for maximum energy efficiency.

Thanks to smart technology, the product gives you control over your energy consumption and will be a key part of your connected home. The efficient control system automatically adjusts the indoor climate for maximum comfort, and you do nature a favour at the same time. * applies to systems which can be connected to NIBE Uplink and myUplink.

NIBE RMU S40

The NIBE RMU S40 is a room unit with 2,8” touch display with built in temperature and humidity sensors. It is used to control and monitor your NIBE S series heat pump/indoor module from another room in the house than the room where the heat pump is placed.

The NIBE S Series is a natural part of your connected home. Smart technology adjusts the indoor climate automatically while you’re in complete control from your phone or tablet. Giving maximum comfort and minimum energy consumption, while doing nature a favour at the same time.
