NIBE SMO 20

Air/Water heat pump
  • Product information
  • Advantages

The NIBE SMO 20 gives optimised control of the climate system and is designed to be combined with NIBE air/water heat pumps to provide an integrated climate system for your home. The control module, NIBE SMO 20, offers a flexible system solution. The NIBE SMO 20 is connected to additional components for efficient heating, cooling and hot water for a customised installation. Thanks to smart technology, the product gives you control over your energy consumption and will be a key part of your connected home. The efficient control system automatically adjusts the indoor climate for maximum comfort, and you do nature a favour at the same time.

Flexible, customised system solution

Connect your heat pump to additional components for efficient heating, cooling and hot water.

Optimum control

User-friendly and intelligent control system for your climate system.

Part of your smart home

Control your comfort online using NIBE Uplink.

  • Functions
  • Accessories
  • Technical data
  • Document
NIBE SMO 20

NIBE Smart Price Adaption

With Smart Price Adaption, the heat pump receives information about the electricity prices for the next 24 hours and then adapts the operation to these. The function is based on information about the hourly prices of the coming day from the electricity exchange NordPool Spot. The prices in combination with expected heating and hot water needs then automatically control the heat pump. This is in order to reduce energy costs and which in the long run contributes to a smaller environmental impact.

NIBE CPD 11-25/75 (UPM2 K 25-75)

NIBE VST 11

Provides the heat pump together with SMO 10 to prioritise hot water charging on systems with floating condensing. This also requires a hot water accumulator, for ex. NIBE VPA. Hot water control for max.electric charge output: 17 kW

NIBE K11

Connections box with thermostat and overheating protection

NIBE IU 3 kW

Electric heating element

NIBE IU 6 kW

Electric heating element

NIBE IU 9 kW

Electric heating element

NIBE VST 20

Makes hot water priority possible at large heat pump outputs. (charging power between 15 and 40 kW), together with an SMO 10 and F1330-40. This also requires a hot water accumulator, for example, NIBE VPA.

NIBE ELK 26

ELK 15 is an immersion heater primarily intended for installation together with heat pump for heating houses or

NIBE VPB 500-1000

The NIBE VPB 500/750/1000 is an efficient, copperlined hot water tank with a wide range of applications which is developed for connection to a heat pump, gas or oil boiler. The NIBE VPB 500/750/1000 has insulation made of Neopor and polyester fleece, which provides low energy loss. The insulation and outer shell are detachable to facilitate installation. The NIBE VPB 500/750/1000 is designed for buildings with large hot water requirements and can be connected in parallel for maximum capacity.

NIBE ELK 15

ELK 15 is an immersion heater primarily intended for installation together with heat pump for heating. NIBE ELK 15 contains overheating protection and contactors to externally regulate the two power groups, 5.0 and 10.0 kW.

NIBE RTS 40

Room sensor used to obtain a more even indoor temperature. RTS 40 has up to three functions:Show current room temperature in the heat pump's display. Option of changing the room temperature in °C. Makes it possible to change/stabilise the room temperature.

NIBE EME 20

Communication and control. EME 20 is used to enable communication and control between the inverter for solarcells and heat pump/indoor module/control module.

NIBE HR 10

Auxiliary relay HR 10 is a connection box housing a contactor and a rotary selector switch. It is used to control external 1 to 3-phase loads such as oil burners, immersion heaters and pumps.

Height (mm)

410

Depth (mm)

110

Net weight (kg)

4
