NIBE F2050 is an intelligent, compact and inverter-controlled air/water heat pump with a more climate-friendly refrigerant. The NIBE F2050 provides optimised savings as the heat pump automatically adapts to your home’s output requirements all year round.
The heat pump operates at an outdoor temperature as low as –20°C and delivers a supply temperature of up to 58°C. The effective cooling function allows the heat pump to deliver a comfortable indoor climate even at high outdoor temperatures. It also has a more climate-friendly refrigerant to reduce its impact on the environment.
Thanks to smart technology, the product gives you control over your energy consumption, and will be a key part of your connected home. The efficient control system automatically adjusts the indoor climate for great comfort, and you do nature a favour at the same time.
Intelligent technology
Compact heat pump that adapts to your home’s requirements
Powerful
High capacity even down to -20°C and effective cooling function
A simpler life
Energy-saving smart technology with user-friendly control
- Functions
- Accessories
- Technical data
- Document
Inverter controlled compressor
The heat pump has an inverter-controlled compressor that helps you as it automatically adapts to your house and supplies your plant with renewable energy.
NIBE Ground mount bracket
For installation on ground.
NIBE Wall bracket
The NIBE BAU 30 wall bracket offers a mounting solution for the F2050-6, F2050-10 and F2050-12 air source heat pumps. The bracket includes adjustable wall and bottom stays, while the supplied vibration dampers reduce transmission of fan and compressor noise into the building. Its compact design, with a depth of 585 mm, enables installation in restricted outdoor spaces. Together, these features make the BAU 30 a practical, robust, and acoustically considerate mounting option for a range of domestic air source heat pump installations.
NIBE KVR 10-10, 1 M
Condensation water pipes for F2040. Different lengths, 1, 3 or 6 m.
NIBE KVR 10-30, 3 M
The NIBE KVR range provides installers with a simple, reliable and freeze protected way to manage condensate drainage from NIBE air source heat pumps. KVR 10 is for the F2050-6 and F2050-10 and is available in multiple lengths, indicated by the suffix; for example, KVR 10-10 = 1 m, KVR 10-30 = 3 m, and KVR 10-60 = 6 m. All variants combine insulated pipework with a thermostat-controlled heating cable that automatically prevents ice formation, ensuring safe drainage even in sub-zero conditions and protecting the heat pump from backflow, frost damage or condensate pooling.
NIBE KVR 10-60, 6 M
The NIBE KVR range provides installers with a simple, reliable and freeze protected way to manage condensate drainage from NIBE air source heat pumps. KVR 10 is for the F2050-6 and F2050-10 and is available in multiple lengths, indicated by the suffix; for example, KVR 10-10 = 1 m, KVR 10-30 = 3 m, and KVR 10-60 = 6 m. All variants combine insulated pipework with a thermostat-controlled heating cable that automatically prevents ice formation, ensuring safe drainage even in sub-zero conditions and protecting the heat pump from backflow, frost damage or condensate pooling.
Height (mm)
791
Width (mm)
993
Depth (mm)
383
Net weight (kg)
76
Product efficiency class room heating, 35 °C
A+++
Product efficiency class room heating, 55 °C
A++
System efficiency class room heating, 55 °C
A++
System efficiency class room heating, 35 °C
A+++
Refrigerant amount, CO2 equivalent (ton)
0,88
NIBE F2050 is a Quiet Mark certified heat pump
Low sound levels for comfort without the noise. Discover how NIBE heat pumps minimize noise while maximizing efficiency.
