NIBE SMO S40

Products for larger properties
  • Product information
  • Advantages

The NIBE SMO S40 gives optimised control of the climate system and is designed to be combined with NIBE air/water heat pumps to provide an integrated climate system for homes and properties.

The NIBE SMO S40 offers high flexibility when it comes to system solutions. The control module can be connected to components such as a water heater, additional heat sources and other accessories specific to a customised installation. Up to eight NIBE air/water heat pumps can be connected to a control system.

With integrated wifi, the S Series is a natural part of your connected home. Smart technology adjusts the indoor climate automatically while you’re in complete control from your phone or tablet. Giving maximum comfort and minimum energy consumption, while doing nature a favour at the same time.

SMART HOME

In combination with a NIBE air/water heat pump – a part of your energy-saving smart home.

USER-FRIENDLY

Smart, user-friendly system with touch control for maximum flexibility.

  • Accessories
  • Technical data
  • Document
NIBE SMO S40

NIBE AXC 30

NIBE SRV 10

Wireless smart radiator thermostat

NIBE EMK 500

Energy metering - 28mm (SMO S40 only)

NIBE CPD 11-25/75

Circulation pump to help move heated water through the heating circuit (such as underfloor heating or radiators). CPD11-25/75 is for up to 7.5m metres of head (pressure) - for larger systems

NIBE K11

Connections box with thermostat and overheating protection

NIBE S135

The NIBE S135 is an exhaust air module designed for docking to a NIBE air/water heat pump and a NIBE VVM indoor module or NIBE SMO control module. The NIBE S135 uses the heat that is found in the house’s ventilation air to heat the house and hot water, at the same time as ventilating the house. In installations with cooling, hot water and cooling can be produced at the same time.

The exhaust air module provides an improved seasonal performance factor and has a low noise level and high ventilation capacity. The NIBE S135 is easy to control through the heat pump’s indoor module.

The NIBE S Series is a natural part of your connected home. Smart technology adjusts the indoor climate automatically while you’re in complete control from your phone or tablet. Giving maximum comfort and minimum energy consumption, while doing nature a favour at the same time.

NIBE IU 6 kW

6kW three phase immersion heater

NIBE VST 20

Makes hot water priority possible at large heat pump outputs. (charging power between 15 and 40 kW), together with an SMO 10 and F1330-40. This also requires a hot water accumulator, for example, NIBE VPA.

NIBE IU 9 kW

9kW three phase immersion heater

NIBE IU 3 kW

Electric heating element

NIBE VST 11

Provides the heat pump together with SMO 10 to prioritise hot water charging on systems with floating condensing. This also requires a hot water accumulator, for ex. NIBE VPA. Hot water control for max.electric charge output: 18 kW

NIBE SOLAR 42

NIBE SOLAR 42 enables solar heating with your heat pump. With additional solar panels and VPBS you get a complete system.

NIBE HR 20

NIBE EMK 300

Energy metering - 22mm

NIBE ELK 42

Back-up electric immersion heater - 42kW

NIBE RPP 10

Enhances the signal, improving communication between your smart home products when they are placed at a distance from each other. For NIBE S- Series heating installations, the repeater functions as a switch, giving you the opportunity to control it remotely, schedule On and Off times and measure energy consumption.

Plug in the repeater and connect it to your NIBE S-Series heating installation.

NIBE ELK 213

Three phase back-up electric immersion heater - 13kW

NIBE ELK 26

Back-up electric immersion heater - 26kW

NIBE ROT 10

The wireless room thermostat allows you to read and control the temperature of a room or a climate zone from the display of the room thermostat or via the myUplink app in your smartphone. For instance by increasing the hot water production when you have many guests or lower the ventilation for better savings when you are not home. Because it is powered by a rechargeable battery, it is easy to install.

Mount the thermostat in your room and connect it to your NIBE S-Series heat pump.

NIBE ELK 213 EXP

Three phase back-up electric immersion heater - 13kW

NIBE CDS 10

This wireless sensor allows you to read the CO2, temperature and humidity level in a room or climate zone using the myUplink app. For NIBE S-series heating installations with ventilation the indoor comfort level can automatically be adjusted to give you a comfortable indoor climate. For example, you can increase ventilation and lower the CO2 level when there are a lot of people present or lower the ventilation to further reduce your energy costs. Because it is battery powered, it is easy to install, but it can also operate with an external power source using a micro USB.

Mount the sensor in your room and connect it to your NIBE S-Series heat and ventilation installation.

NIBE ELK 15

Three phase back-up electric immersion heater - 15kW

NIBE THS 10

This wireless sensor allows you to read the temperature and humidity in a room or climate zone using the myUplink app. On the heat pump you can see the current room temperature or change it in °C. THS 10 replaces the fixed indoor sensor. Because it is battery powered, it is easy to install.

Mount the sensor in your room and connect it to your NIBE S-Series heating installation.

NIBE POOL 40

An accessory that allows pool heating using heat pump. Max 18 kW. The heat pump controls the reversing valve, pool circulation pump and any heating circuit circulation pumps via POOL 40.

NIBE RMU S40

The NIBE RMU S40 is a room unit with 2,8” touch display with built in temperature and humidity sensors. It is used to control and monitor your NIBE S series heat pump/indoor module from another room in the house than the room where the heat pump is placed.

The NIBE S Series is a natural part of your connected home. Smart technology adjusts the indoor climate automatically while you’re in complete control from your phone or tablet. Giving maximum comfort and minimum energy consumption, while doing nature a favour at the same time.

NIBE HR 10

Auxiliary relay HR 10 is a connection box housing a contactor and a rotary selector switch. It is used to control external 1 to 3-phase loads such as oil burners, immersion heaters and pumps.

NIBE EME 20

Communication module that translates Modbus RTU, from a solar inverter, to Modbus TCP/IP, for the heat pump to control the solar inverter

NIBE ECS 40

ECS 40 is used when heat pump is installed in houses with up to four different climate systems that require different flow line temperatures, for example, in cases where the house has both a radiator system and an under floor heating system.

NIBE ECS 41

Allows the heat pump to control a second heating circuit (zone) with a different temperature requirement. For more than 80 m² of underfloor heating

Height (mm)

350

Width (mm)

540

Depth (mm)

110

Net weight (kg)

5

User manual (UHB)
Installer manual (IHB)
Product leaflet (PBD)
Product catalogue (KBR) NIBE S Series heat pumps
Product catalogue (KBR) Air/water heat pumps
Consumer information leaflet (CIL)
